Videohub Smart Control
Technical Specifications
Description
When you want the fastest routing you can get, then Videohub Smart Control lets you route with a single button press. Program each button for a single router cross point and when pressed the route is made. You can program to have multiple destinations and even a take button! Powers via DC or the Ethernet connection!
Price
$495
Connections
Ethernet
RJ45 Ethernet with Power over Ethernet supported, without power supplied on loop Ethernet output.
Power
+12V DC input
Macro Capability
Up to 10 Macro buttons can be assigned to activate multiple simultaneous switching commands.
Hardware Control
40 programmable buttons and RJ45 Ethernet used for remote control of routers over an IP network.
Software
Internal Software upgrade via included firmware updater application via USB
Operating Systems
Mac OS X 10.10 Yosemite,
Mac OS X 10.11 El Capitan or later.
Windows 8.1 or Windows 10.
Physical Installation
1 rack unit size. Less than an inch deep.
Power Requirements
Power Fail Protection
Button configurations and router communication preserved and restored instantly at power on. Button configuration can also be saved for later recall.
Power Supply
1 x Universal power supply included with international socket adapters for all countries.
What's Included
Videohub Smart Control
Universal power supply included with international socket adapters
Warranty
12 Months Limited Warranty.
