SDI Video Inputs

1 x SD, HD and 3G-SDI Video and 1 x Optical Fiber Input.

SDI Video Outputs

Automatically matches the SD, HD and 3G-SDI video input on the SDI Video and Optical Fiber output.

Optical Fiber Video Inputs

1 x 10 bit SD/HD/3G- SDI switchable.

Optical Fiber Video Outputs

1 x 10 bit SD/HD/ 3G-SDI switchable.

Optical Fiber Audio Inputs

16 channel embedded.

Optical Fiber Audio Outputs

16 channel embedded.

Multi Rate Support

Auto detection of SD, HD or 3G-SDI.

Reclocking

Yes

SD Video Standards

525i59.94 NTSC, 625i50 PAL

HD Video Standards

720p50, 720p59.94, 720p60
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60 1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97, 1080PsF30
1080i50, 1080i59.94, 1080i60

2K Video Standards

2K DCI 23.98p, 2K DCI 24p , 2K DCI 25p
2K DCI 23.98PsF, 2K DCI 24PsF , 2K DCI 25PsF

SDI Compliance

SMPTE 259M, SMPTE 292M , SMPTE 296M , SMPTE 424M-B , ITU-R BT.656 , ITU-R BT.601 and SMPTE 297M for Optical Fiber SDI.

SDI Video Rates

SDI video connections are switchable between standard definition and high definition.

SDI Video Sampling

4:2:2

SDI Audio Sampling

Television standard sample rate of 48 kHz and 24 bit .

SDI Color Precision

4:2:2

SDI Color Space

YUV

SDI Auto Switching

Automatically detects SD, HD or 3G-SDI .

ASI Support

Yes

macOS 10.12 Sierra,
macOS 10.13 High Sierra or later,

Power Supply

+12V universal power supply included with international socket adapters for all countries. Cable tie point.

Power Consumption

3.84 Watts

Operational Voltage Range

12V DC

Operating temperature

0° to 40° C (32° to 104° F)

Storage temperature

-20° to 45° C (-4° to 113° F)

Relative Humidity

0% to 90% non-condensing
