Sensors

2 x 8K sensors.

Left eye and right eye.

Effective Sensor Size

23.66 mm x 20.88 mm each.

Pixel Pitch

2.9 microns.

Lens

Fixed focal length, 180°+ field of view, stereo lens pair.

Dynamic Range

16 Stops.

Shooting Formats

8160 x 7200 x 2 (stereo immersive)

Frame Rates

Project frame rates of 23.98, 24, 25, 29.97, 30, 50, 59.94, 60 and 90 fps supported.

High Speed Frame Rates

8K stereo immersive up to 90 fps.

Built in ND Filters

Button activated ND filters with clear, 2‑stop, 4‑stop, 6‑stop and 8‑stop IR ND filters.

Iris Control

Fixed iris.

Screens

2 x Monitoring Screens.

1 x Camera Status Screen.

Monitoring Screen Dimensions

5 inch.

Monitoring Screen Resolution

1920px x 1080px.

Monitoring Screen Brightness

1500 nits.

Monitoring Screen Type

LCD capacitive touchscreen.

Monitoring Options

Left Eye, Right Eye, Punch In.

Metadata Support

Discrete left and right eye optical calibration metadata. Automatic recording of camera settings and slate data such as project, scene number, take and special notes.

Controls

Touchscreen menus on 5 inch screen. Push buttons for other controls. 7 assignable shortcut keys plus 3 assignable shortcut keys on PYXIS Monitor. Fischer connector for remote run/stop.

Timecode Clock

Highly accurate timecode clock. Less than 1 frame drift every 8 hours.

Total Video Outputs

2

SDI Rates

1.5G, 3G, 6G, 12G.

Analog Audio Inputs

2 x XLR analog switchable between mic, line and AES audio. Phantom power support.

Analog Audio Outputs

1 x 3.5mm headphone jack.

Reference Inputs

Tri-Sync/Black Burst and Timecode.

USB-C Monitor Outputs

2 x USB-C side monitor ports support URSA Cine EVF, PYXIS Monitor or DisplayPort monitors.

Computer Interface

2 x USB-C side expansion ports for camera accessories.

Software updates using side USB-C closer to rear.

Ethernet

1 x 10Gb/s RJ‑45 connector supporting 10/100/1000/10G BASE-T for SMB file sharing, Web Media Management, Blackmagic Cloud uploads, camera control and streaming.

Microphone

Integrated stereo microphone.

Built in Speaker

1 x mono speaker.

SD Video Standards

None

HD Video Standards

1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30, 1080p50, 1080p59.94, 1080p60, 1080i50, 1080i59.94, 1080i60

Ultra HD Video Standards

2160p23.98, 2160p24, 2160p25, 2160p29.97, 2160p30, 2160p50, 2160p59.94, 2160p60

SDI Compliance

SMPTE 292M, SMPTE 424 Level B, SMPTE 2081-1, SMPTE 2082-1

SDI Audio Sampling

48 kHz and 24 bit.

Media

1 x Blackmagic Media Module.

Media Format

Blackmagic

Codecs

Blackmagic RAW Constant Bitrate 5:1
Blackmagic RAW Constant Bitrate 8:1
Blackmagic RAW Constant Bitrate 12:1
Blackmagic RAW Constant Bitrate 18:1
Blackmagic RAW Constant Quality Q0
Blackmagic RAW Constant Quality Q1
Blackmagic RAW Constant Quality Q3
Blackmagic RAW Constant Quality Q5

NTP

Network time protocol support allows you to sync the time on your camera, whenever connected to a network with any NTP server of your choice.

FTP

Download files from any drive attached to your camera using FTP.

Web Media Manager

Using a browser connected over Ethernet, web media manager allows you to access, browse, download and delete files from any drive connected to the camera.

SMB

File sharing using SMB.

Power Supply

+24V DC external power supply 100 - 240 AC 50/60Hz compatible with IEC C14 socket.

B-Mount battery plate.

Power Input

1 x 8 pin Lemo compatible socket for external power or battery use.

Molex connector for rear battery plate.

Power Output

B-Mount battery plate including 2-pin connector with +12V regulated output from camera.

Operating Temperature

0° to 40°C (32° to 104°F)

Storage Temperature

-20° to 45°C (-4° to 113°F)

Relative Humidity

0% to 90% non-condensing

1 Year Limited Manufacturer’s Warranty.
